#CABLE TV RF ISOLATOR MANUAL#
Outdoor mounting, mast clamp and user manual in CDROM format.įull galvanic isolation between connected radio equipment. Connector option: N SKU: HST-212NĪntenna Galvanic Isolator. Outdoor mounting version optionsĪntenna Galvanic Isolator Outdoor version. Same noisy situation but with plugged-in Antenna Galvanic Isolator.ġ0kHz - 150MHz Antenna Galvanic Isolator. "Frying noise" on receiver antenna port without Antenna Galvanic Isolator. It allows isolate the antenna galvanically from the receiver only magnetic signal is coupling from the antenna.Ĭover: ABS material rated to UL 94V-0. Outdoor version of the above broadband antenna galvanic isolator. Hi-Power 10kHz - 150MHz LF-HF-VHF Antenna Galvanic Isolator. Connector option: N SKU: HS-100Nġ0kHz to 150MHz Antenna Galvanic Isolator and user manual in CDROM format. Hi-Power 10kHz to 150MHz Antenna Galvanic Isolator. Same noisy situation but with in-line plugged-in Antenna Galvanic Isolator. "Frying noise" on receiver antenna port without in-line Antenna Galvanic Isolator. Hi-Power 10kHz to 150MHz Antenna Galvanic Isolator datasheet. Insertion loss ( attenuation) in function of frequency. Earth terminal post for antenna separate earth connection. Connector Options: SO-239, BNC, "N type " available. Power rating: 200 watts continuous wave.(400watts PEP) Flat response along the covered range of frequencies. It includes gas discharge tube as protection against electrostatic discharges. It embedded a high isolation broadband transformer wound on a large toroid core 200 Watts power rated. The Antenna Isolator can achieve up to 40dB noise rejection, depending on installation.
This can cause mains noise to enter into the receiver because either the feeder mains earth line is the return path for the antenna or noise being coupled to the antenna and radiated. In most station installations the antenna coaxial feeder is connected to mains earth at the receiver side. This type of ground loop issue can be solved by using galvanic isolation between the receiver earth system and the antenna earth. Ground loops in SDR radios induced by the antenna feeder are very common if the computer ground is connected to the radio system increasing local background noise. The indoor broadband antenna galvanic isolator allows isolate the antenna galvanically from the receiver only magnetic signal is coupling from the antenna. Specifically recommended to work with SDR radios. Rejects pick-up noise from the antenna feedline by removing ground loops. 1 CATV RF Forward Receiver with Return Path Optical Transmitter.Galvanic Isolators from Heros Technology Ltd.In some cases when Cable TV service on demand is required Bidirectional RF Fiber brake is required Protect your facility today with low-cost RF Fiber Breaks from Thor. Coax cabling represents a serious security vulnerability to any location with access to highly sensitive data. Our standard units are for CATV band 45-870 MHz, but we can also provide units for satellite bands as well as other communication system frequencies. Because of the nature of RF over fiber systems, signals can only travel in one direction without return path optics. These units are for short distance RF over fiber applications to create a single direction RF Fiber Break. Often times this is required for high security and military applications.
This prevents signals from being passed in the return direction. RF Fiber Breaks are used to transport the RF over a single directional fiber link. Low-cost RF Fiber Break for military and high-security applications.
fiber optic jumpers SC/APC to connect TX and RX together.
#CABLE TV RF ISOLATOR PORTABLE#
Portable CATV fiber optic receiver - converts modulated light to electrical RF.19" Rackmountable CATV fiber optic Transmitter- converts electrical CATV RF to modulated light signal.RF Cable TV (CATV) Fiber Optic Transmitter/ Receiver Break System For High Security
